FP6185代理，输出由3.3V,3V,2.9V.2.8V2.7V等
详情
Description
The FP6185 is a low dropout, low noise, high PSRR, very low quiescent current positive linear regulator.The FP6185 can supply 300mA output current with low dropout voltage at about 400mV that optimized for battery- powered systems or portable wireless devices suchas mobile phones. The shutdown function can provide remote control for the external signal to decide the on/off state of FP6185 that consumes less than 0.1µA during shutdown mode.
The FP6185 regulator is able to operate with output capacitors as small as 1µF for stability. Other than the current limit protection, FP6185 also offers the on chip thermal shutdown feature providing protection against overload or any condition when the ambient temperature exceeds the maximum junction temperature.
The FP6185 offers high precision output voltage of2%.The FP6185 is available in SOT-23-5 package which features small size.
The FP6185 is a low dropout, low noise, high PSRR, very low quiescent current positive linear regulator.The FP6185 can supply 300mA output current with low dropout voltage at about 400mV that optimized for battery- powered systems or portable wireless devices suchas mobile phones. The shutdown function can provide remote control for the external signal to decide the on/off state of FP6185 that consumes less than 0.1µA during shutdown mode.
The FP6185 regulator is able to operate with output capacitors as small as 1µF for stability. Other than the current limit protection, FP6185 also offers the on chip thermal shutdown feature providing protection against overload or any condition when the ambient temperature exceeds the maximum junction temperature.
The FP6185 offers high precision output voltage of2%.The FP6185 is available in SOT-23-5 package which features small size.
|
|
|
Features Low V IN and Wide V IN Range: 2V to 5.5V Output Current 300mA *1 2% Output Voltage Accuracy Output Noise 65 μ Vrms from 10Hz to 100kHz V OUT Fixed 1.0V to 3.3V Low Dropout Voltage of 400mV at 300mA Ripple Rejection 75dB at 1KHz Very Low Quiescent Current at 35µA Needs Only 1µF Capacitor for Stability Thermal Shutdown Protection Current Limit Protection SOT-23-5 Package RoHS Compliant * 1. Attention should be paid to the power dissipation of the package when the output current is large. |
|
Applications PDAs, Mobile phones, GPS, Smartphones Wireless Handsets, Wireless LAN, Bluetooth® , Zigbee® Portable Medical Equipment Other Battery Powered Applications
代理商： |
