高耐壓的LDO穩壓芯片PW8600，輸齣5V.3.3V和3V，PW8600支持60V輸入範圍，PW6206支持40V輸入範圍。
PW8600,PW6206代理商
深圳市誇剋微科技
鄭先生 ：13528458039
QQ 2867714804
PW8600概述：
PW8600 series is designed for power sensitive applications. It includes a precision and high voltage input stage, an ultracurrent branch, and results in a ultra and low-dropout linear regulator. The PW8600 operates from an input volta of VOUT+1V to 65V, consumes only quiescent current, and offers 1% initial accuracy and low dropout voltage, 70mV typical at 10mA.
PW8600 is a fixed output LDO with available has available voltages at 3V to 5.0V. Other features include short-circuit protection and thermal shutdown.
FEATURES
l Wide Operating Voltage: VOUT+1V to 65V ( max Vin can be up to 80V)
l Ultra Low Quiescent Current : 1.8uA(Typ.)
l Output accuracy: ±2%
l High output current: ≥200mA
l Low Dropout Voltages: 70mV@10mA, 700mV@100mA
l System startup with no overshoot
l Short circuit protection is designed with no overshoot
l Excellent power / load transient response
l Low temperature coefficient:
l Packages：SOT23-3
